Home > PC Parts > Networking > Antennas > Ubiquiti PowerBeam M5 AC 500 27dBi 5GHz 802.11ac 2x2 MIMO Antenna (PBE-5AC-500-AU)

Ubiquiti PowerBeam M5 AC 500 27dBi 5GHz 802.11ac 2x2 MIMO Antenna (PBE-5AC-500-AU)

$259.0

or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time : Question Mark

Get a $5 credit or a free drink if order not ready on pick up time.

Delivery: Question Mark

Next Day Dispatch - Order within 43hrs and 5mins

- +

Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Wish Add to Wishlist

Your Store

Your store is set to:

Check live stock level

Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

Product Name:

Ubiquiti PowerBeam M5 AC 500 27dBi 5GHz 802.11ac 2x2 MIMO Antenna (PBE-5AC-500-AU)
Model Number:

PBE-5AC-500-AU
Brand:

Ubiquiti
Warranty Period:

1 Year

Description

Ubiquiti PowerBeam M5 AC 500 27dBi 5GHz 802.11ac 2x2 MIMO Antenna

Incorporating a dish reflector design with proprietary airMAX® ac technology, the PowerBeam™ ac is ideal for CPE deployments requiring maximum performance.

Ubiquiti PowerBeam M5 AC 500 27dBi 5GHz 802.11ac 2x2 MIMO Antenna (PBE-5AC-500-AU)

Specifications

DIMENSIONS	Radome Excluded	Radome Included
	520 x 520 x 308 mm (20.47 x 20.47 x 12.13")	525 x 525 x 315 mm (20.67 x 20.67 x 12.40")
WEIGHT	Radome Excluded	Radome Included
	2.35 kg (5.18 lb)	3.15 kg (6.95 lb)
POWER SUPPLY	24V, 0.5A Gigabit PoE
MAX. POWER CONSUMPTION	8.5W
POWER METHOD	Passive PoE (Pairs 4, 5+; 7, 8 Return)
SUPPORTED VOLTAGE RANGE	20-26VDC
OPERATING FREQUENCY	5150 - 5875 MHz
GAIN	27 dBi
NETWORKING INTERFACE	(1) 10/100/1000 Ethernet Port
PROCESSOR SPECS	Atheros MIPS 74Kc, 720 MHz
MEMORY	128 MB DDR2, 16 MB Flash
LEDS	(1) Power, (1) LAN, (4) WLAN
SIGNAL STRENGTH LEDS	Software-Adjustable to Correspond to Custom RSSI Levels
MAX. VSWR	1.5:1
CHANNEL SIZES	PtP Mode	PtMP Mode
	10/20/30/40/50/60/80 MHz	10/20/30/40 MHz
POLARISATION	Dual Linear
ENCLOSURE	Outdoor UV Stabilized Plastic
MOUNTING	Pole-Mount (Kit Included)
WIND LOADING	264.6 N @ 96 km/h (60 lbf @ 60 mph)
WIND SURVIVABILITY	96 km/h (60 mph)
ESD/EMP PROTECTION	Air: ± 24 kV, Contact: ± 24 kV
OPERATING TEMPERATURE	-40 to 70° C (-40 to 158° F)
OPERATING HUMIDITY	5 to 95% Noncondensing
WIRELESS APPROVALS	FCC, IC, CE
ROHS COMPLIANCE	Yes
SALT FOG TEST	IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
VIBRATION TEST	IEC 68-2-6
TEMPERATURE SHOCK TEST	IEC 68-2-14
UV TEST	IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
WIND DRIVEN RAIN TEST	ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
