SPECIFICATIONS:
Dimensions
87 x 44 x 29 mm
(3.43 x 1.73 x 1.14")
Weight
99.4 g (3.51 g)
Output voltage
24VDC @ 0.5A
LAN activity indicator
No
Gigabit LAN port
Yes
Remote reset capability
Reset button
Rated voltage
100-240VAC @ 50/60Hz
Input current
0.3A @ 120VAC,
0.2A @ 240VAC
Inrush current
<30A Peak @ 120VAC,
<60A Peak @ 230VAC
Efficiency
75+%
Output ripple
1% Max.
Switching frequency
50 kHz
Line regulation
≤ 3%
Load regulation
≤ 5%
2 pair powering
Pins 4, 5 (+) and Pins 7, 8 (-)
4 pair powering
-
Operating temperature
0 to 40° C (32 to 104° F)
Storage temperature
-30 to 70°C (-22 to 158° F)
Operating humidity
35 to 95% Noncondensing
AC connector
IEC-320 C6
Data in/PoE
RJ45 Shielded Socket
Surge protection
Difference and Common Mode
Clamping protection
11V Data, 60V Power
Max. Surge discharge
1500A (8/20 µs) Power
Peak pulse current
36A (10/1000 µs) Data
Shunt capacitance
<5 pF data
Response time
<1 ns
Certifications
CE, FCC, IC, UL
