MECHANICAL |
|
Dimensions       | 747 x 525 x 347 mm (29.41 x 20.67 x 13.66") |
Weight | 3.2 kg (7.06 lb) |
Enclosure materials       | Aluminum alloy, UV stabilized polycarbonate |
Mount material | UV stabilized polycarbonate |
Mounting           | Integrated pole mount (included) Pole compatibility: Ø35 to 60 mm (Ø1.38 to 2.36")          |
Wind loading    | 1100 N at 200 km/h (247.29 lbf at 125 mph) |
Weatherproofing            | IPX6 |
HARDWARE |
|
Networking interface   | (1) GbE RJ45 port |
Power method | Passive PoE 2-pair (4, 5+; 7, 8-) |
Power supply   | 24V DC, 0.5A Gigabit PoE adapter (included) |
Supported voltage range             | 22—26V DC |
Max. power consumption           | 7W |
RF connections | Internal |
LEDs      | Power/ethernet |
Button | Factory reset |
Operating temperature | -40 to 70° C (-40 to 158° F) |
Operating humidity       | 5 to 95% non-condensing |
Certifications    | FCC, IC, CE |
SYSTEM |
|
Maximum throughput  | 450+ Mbps |
Encryption         | WPA2-PSK (AES) |
SOFTWARE |
|
Modes | PtMP, PtP |
Services              | SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog |
Utilities | airView®, speed test, alignment, discovery, ping, traceroute, constellation |
Management interface | Dedicated management radio for quick device setup via the UISPâ„¢ Mobile app WEB UI |
Minimum software requirements           | Modern Web browser or Android/iOS smartphone |
RF |
|
Operating frequency*Â Â | 5.15 to 5.85 GHz * Depends on regulatory region. |
Max. conducted TX power          | 25 dBm |
Management radio        | 2400 - 2483.5 MHz |
Channel bandwidth       | 10/20/30/40/50/60/80 MHz |
Antenna Gain   | 29 dBi |
Isolation             | 20 dB |
Beamwidth       | HPOL: 3 dB: 5.5°, 6 dB: 7.5° VPOL: 3 dB: 5.5°, 6 dB: 7.5°         Elevation: 3 dB: 5.5°, 6 dB: 7.5° |
Electrical downtilt          | 0° |
