HARDWARE |
|
Standard&Protocol | IEEE802.3, IEEE802.3u,IEEE802.3ab |
Interfaces | 1*10/100/1000Mbps WAN port 4*10/100/1000Mbps LAN ports USB2.0*1 |
Antenna | 4*6dBi external antennas |
Button | 1* WPS/Reset button |
Power | Input：AC 100-240V~50/60Hz 0.6A Output：DC 12V2A |
Dimension | 9.41 * 5.68 * 1.59 in (238.9X144.3X40.3mm) |
LED Indicator | Sys*1,WAN*1, LAN*1,WiFi/WPS*1 |
WIRELESS |
|
Wireless Standard | IEEE 802.11ac wave2/a/n 5GHz IEEE 802.11b/g/n 2.4GHz |
Data Rate | 5GHz: Up to 1733Mbps 2.4GHz: Up to 300Mbps |
Frequency | Simultaneous dual band 2.4 & 5GHz |
Transmission Power | CE: <20dBm(2.4G) <23dBm(5G) |
Basic Features | SSID Broadcast: Enable/Disable Transmission Power: high, medium, low Beamforming MU-MIMO |
Wireless Security | WPA-PSK/WPA2-PSK, WPA/WPA2 Wireless Security: Enable/Disable WPS(WiFi Protected Set-up) fast encryption |
SOFTWARE |
|
Internet Connection Type | PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) |
Operating Mode | Wireless Router Mode Universal Repeater Mode WISP Mode |
DHCP Server | DHCP Server DHCP Client List DHCP Reservation |
Virtual Server | UPnP DMZ Host Port Forwarding |
Security | Client Filter Parental Control(support black list and white list) Remote Web Management |
Firewall | Forbid UDP flood attack Forbid TCP flood attack Forbid ICMP attack Forbid WAN PING from internet |
DDNS | no-ip,DynDNS,Oray, 88ip |
VPN | IPsec pass through PPTP pass through L2TP pass through PPTP server PPTP client L2TP client |
Special Features | Smart Traffic Prioritisation PPPoE Username/password Clone Smart WiFi Schedule Smart Power Saving Smart LED on/off Tenda Cloud Tenda App |
Others | Bandwidth Control Guest Network IPTV MAC Clone Static Routing System Log Backup & Restore configurations Firmware upgrade online Firmware upgradeable via browser Supports IPv6 Alexa |
OTHERS |
|
Temperature | Operating Temperature: 0℃ ~ 40℃ Storage Temperature: -40℃ ~ 70℃. |
Humidity | Operating Humidity:10% ~ 90% RH non-condensing Storage Humidity: 5% ~ 90%RH non-condensing. |
Default Settings | Default Access: tendawifi.com |
Certification | CE/FCC/RoHS |
EIRP Power (Max) | 2.400-2.4835GHz:19.86dBm (EIRP) 5.150-5.250GHz:22.96dBm (EIRP) |
Package Contents | Wireles Router*1 Power Adapter *1 Install Guide*1 Ethernet Cable*1 |
