TOPOLOGY | Line-Interactive High Frequency (Pure Sinewave, Booster + Fader) |
CONFIGURATION | Tower |
PART NUMBER | 5P850AU |
RATING (VA/WATTS) | 850/600 |
DIMENSIONS (H X W X D, MM) | 230 x 150 x 345 |
WEIGHT (KG) | 10.4 |
WARRANTY | 3 years on electronics, 2 years on batteries |
CONTENTS
(SHIPS WITH THE FOLLOWING ITEMS) | 5P UPS
Eaton Intelligent Power Software CD
USB cable
Serial cable
Safety guide
Quick start guide
CD with 10-language user manual |
CONNECTION | (1) Aust. 10A |
INPUT VOLTAGE WITHOUT USING BATTERIES | 160V-294V (adjustable to 150V-294V) |
INPUT FREQUENCY RANGE WITHOUT USING BATTERIES | 47 to 70Hz (50 Hz system), 56.5 to 70Hz (60 Hz system), 40Hz in low-sensitivity mode |
RATING (VA/WATTS) | 850/600 |
VOLTAGES | 230 V (+6/-10 %) (Adjustable to 200V / 220V / 230V / 240V) |
OUTPUT RECEPTACLES | (3) IEC-320-C13, (2) Aust. 10A |
REMOTELY CONTROLLED SOCKETS | 2 groups of 1 x AU (10 A) output receptacles |
OUTPUT FREQUENCY | 50/60 Hz +/- 0.1 % (autosensing) |
BATTERY MANAGEMENT | ABM® & temperature compensated charging method (user selectable), automatic battery test, deep discharge protection |
COLD START (NO MAINS POWER) | Yes |
USER INTERFACE | 3 LEDS + Multilingual LCD : access to measures, alarm messages and customization |
COMMUNICATION PORTS | 1 USB port + 1 RS232 serial port and relay contacts (USB and RS232 ports cannot be used simultaneously), 1 mini-terminal block for remote ON/OFF and Remote Power Off |
COMMUNICATIONS CARD SLOTS | 1 slot for Network-MS card, ModBus-MS or Relay-MS cards |
AUDIBLE NOISE | < 40 dBA |
OPERATING TEMPERATURE | 0 to 35°C |
SAFETY MARKINGS | IEC/EN 62040-1 |
EMC MARKINGS | IEC/EN 62040-2 class B (EMC), IEC/EN 62040-3 (performance), C-Tick |
APPROVALS | CE, CB report |
QUALITY | Designed, manufactured and marketed under ISO9001 & ISO14001 quality system |
