Engine | Mono Laser |
Print Engine Series | ELL |
Functions | A4 Duplex Wireless Network Mono Laser Printer |
CPU Speed | 600Mhz |
Standard Memory | 64MB |
Optional Memory | NA |
LED Display | Green (Wi-Fi) |
LCD Display | 16 characters x 1 line |
LCD Display Back-Light | NA |
Control Panel Switches | Go, OK, Back, +, -, Power On/Off, Wi-Fi |
Print Speed | Up to 30 ppm |
2 Sided Print | Yes (Automatic) |
2 Sided Print Speed | Built-in @ Up to 15 sides per minute (7.5 sheets per minute) |
Printer Resolution | 600 x 600 dpi, HQ1200 (2400 x 600 dpi) quality, 1200 x 1200 dpi |
First Print Out Time | Less than 8.5 secs from ready mode, Less than 17.5 secs from sleep mode |
Warm Up Time | Less than 9 secs from sleep modeLess than 26 secs from power on |
Emulation | GDI |
Resident Fonts | NA |
Resident Font BR-Script 3 | NA |
Resident Font PCL | NA |
Resident Barcodes | NA |
Quiet Mode | Yes |
Digital Copier |
|
Copier Speed | NA |
First Copy Out Time | NA |
Copier Resolution | NA |
Copier Multi Sort | NA |
Copier Multi Stack | NA |
Copier N-in-1 | NA |
Interface | USB 2.0 @ Hi-Speed, IEEE 802.11b/g/n Wireless, IEEE 802.11g/n (Wi-Fi Direct) |
USB Interface | Hi-Speed USB 2.0 |
Interface Parallel | NA |
Wired Interface | NA |
Wireless Interface | IEEE 802.11b/g/n (Infrastructure Mode), IEEE 802.11g/n (Wi-Fi Direct) |
Wireless Mode | IEEE 802.11b/g/n (Infrastructure Mode) IEEE 802.11g/n (Wi-Fi Direct) |
Wireless Setup Support Utility | Wi-Fi Protected Setupďż˝ (WPS) |
Wi-Fi Direct | IEEE 802.11g/n (Wi-Fi Direct) |
NFC | NA |
Network Protocols IPV4 | ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print) |
Network Protocols IPV6 | NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, Web Services (Print) |
Active Directory Authentication | NA |
LDAP | NA |
Brother Solutions Interface | NA |
Wireless Security Protocols | WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES) |
Wireless Security | - |
Wired Security | - |
Wireless Certification | Wi-Fi Certification Mark License (WPAďż˝/WPA2ďż˝ - Personal), Wi-Fi Protected Setup (WPS) Identifier Mark License, Wi-Fi CERTIFIED Wi-Fi Direct |
IP-Filter V4 | Yes (IPV4 Only) |
Secure Function Lock | NA |
Secure Print | NA |
Network Management | Windows:BRAdmin Light, Web Base Management, BRAdmin ProfessionalMac: Web Base ManagementLinux: Web Base Management |
Web Based Management | Yes |
Web BRAdmin | NA |
BRAdmin Light | Windows: Yes (Download from Brother Solutions Centre) |
BRAdmin Professional | Yes (Download from Brother Solutions Centre) |
Email Alerts | E-mail Reports and Notification |
Store Print Log to Network | NA |
Driver Deployment Wizard | Yes |
iPrintScan | Yes (Print Only) |
Google Cloud Print | Yes |
AirPrint | Yes |
Mopria | Yes |
Web Connect | NA |
Printer Compatibility | Windows 10 (32&64bit), Windows 8, 8.1 (32&64bit), Windows 7 (32&64bit), Windows Server 2016, Windows Server 2012 (32&64bit), Windows Server 2012 R2, Windows Server 2008 (32&64bit), Windows Server 2008 R2Mac OS X 10.10.5 or greater (Download)Linux Cups, LPD/LPRng |
Software Available | Windows: Status Monitor, BRAdmin Light�, BRAdmin Professional�, Driver Deployment Wizard�Mac: Status Monitor, BRAdmin (Light)� |
Software Included | Windows: Printer Drivers, Status Monitor, BRAdmin Light, Driver Deployment WizardMac: (Download above software for Mac from Brother Solutions Centre) |
Manual Duplex | Yes |
Cerner Certified | NA |
Status Monitor | Yes |
Watermark Printing | Yes (Windows only) |
Archive Printing | Yes (Windows Only) |
Header and Footer Printing | Yes (Windows only) |
N-up Printing | 2, 4, 9, 16, 25 in 1 page (Windows), 2, 4, 6, 9, 16 in 1 page (Mac) |
Poster Printing | 1 in 2x2, 3x3, 4x4, 5x5 (Windows Only) |
Printer Driver Functions | N in 1, Manual Duplex (Windows/Mac)Poster, Header-Footer, Watermark, Archive Print (Windows Only) |
Paper Handling |
|
Standard Paper Capacity | Up to 250 sheets |
Multi-Purpose Tray Capacity | NA |
Manual Feed Slot | 1 sheet |
Optional Paper Tray | NA |
Envelopes Input | 1 envelope face up (Manual feed slot only) output via rear |
Output Paper Capacity | Up to 150 Sheets Face Down (80gsm)1 sheet face-up (straight paper path) |
Carbon Copy | NA |
Media Size Paper Tray | A4, Letter, A5, A5(Long Edge), A6, Executive |
Media Size Paper Tray (Option) | NA |
Media Size MP Tray | NA |
Media Size Manual Feed Slot | Width 76.2 to 215.9 mm, Length 127 to 355.6 mmEnvelope: COM-10, DL, C5, Monarch |
Media Size Duplex | A4 |
Media Types Paper Tray | Plain Paper, Thin Paper, Recycled Paper, Thick Paper |
Media Types Paper Tray (Option) | NA |
Media Types MP Tray | NA |
Media Types Manual Feed Slot | Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env.Thin, Env.Thick |
Media Types Duplex | Plain Paper, Thin Paper, Recycled Paper |
Media Weights Paper Tray | 60-163 gsm |
Media Weights Paper Tray (Option) | NA |
Media Weights MP Tray | NA |
Media Weights Manual Feed Slot | 60-230 gsm |
Media Weights Duplex | 60-105 gsm |
Media Low or Out Sensor | NA |
Media Output Sensor | NA |
Print Paper Margin | 4.2, 4.2, 4.2, 4.2mm (top, bottom, left, right) |
Consumable |
|
Consumables | Standard Toner Cartridge (TN-2430) Up to 1,200 A4 pages @ ISO/IEC 19752High Yield Toner Cartridge (TN-2450) Up to 3,000 A4 pages @ ISO/IEC 19752Drum (DR-2425) Up to 12,000 A4 pages (1 page / job) |
Inbox Consumables | Inbox Toner Cartridge Up to 700 pages @ ISO/IEC 19752Drum (DR-2425) Up to 12,000 pages (1 page / job) |
Size | 356(W) x 360(D) x 183(H)mm |
Weight | 7.2 Kg with consumables |
Size With Carton | 438(W) x 283(D) x 519(H)mm |
Weight With Carton | 8.3 Kg with consumables |
Sleep Mode | Yes (0-50 min) |
Power Consumption | Printing: 460W or lessStandby: 48W or lessSleep: 3.9W or lessDeep Sleep: 0.5W or less |
Ecology | Power Saving, Toner Saving |
TEC Value | 1.18kWh / Week |
Noise Level | Sound Pressure: Printing: 48dB or less, Standby:30dB or less Sound Power: Printing: 6.56B, Standby: Inaudible |
Energy Star Compliant | Yes |
Temperature | Operating: 10 - 32°CStorage: 0 - 40°C |
Humidity | Operating: 20 - 80% (without condensation)Storage: 35 - 85% (without condensation) |
Toner Save | Yes |
Power Save | Yes |
