High video resolution – up to 1600 x 1200 @ 60Hz- 32 bit color depth for the local console; up to 1600 x 1200 @ 60Hzwith 24 bit color depth for remote sessions
Virtual Media Support
Mouse Dynasync
Specifications
Connectors
Console Ports
1 x SPHD-18 Male (Yellow)
KVM (Computer) Ports
1 x SPHD-15 Female (Yellow)
Virtual Media
1 x USB Mini Type B Female (Black)
PON
1 x DB-9 Male (Black)
Modem
1 x DB-9 Male (Black)
LAN Ports
1 x RJ-45 Female
Power
1 x DC Jack
Switches
Reset
1 x Semi-recessed Pushbutton
LEDs
Power
1 (Orange)
Link
1 (Green)
10/100 Mbps
1 (Orange/Green)
Emulation
Keyboard / Mouse
USB; PS/2
Video
Up to 1600 x 1200 @ 60 Hz; DDC2B
Power Consumption
DC5.3V:6.80W:36BTU
Environmental
Operating Temperature
0 - 50°C (CN8000) 0 - 40°C (Power Adapter)
Storage Temperature
-20 - 60°C
Humidity
0 - 80% RH, Non-condensing
Physical Properties
Housing
Metal
Weight
0.49 kg ( 1.08 lb )
Dimensions (L x W x H)
20.20 x 8.64 x 2.50 cm (7.95 x 3.4 x 0.98 in.)
Note
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
