Aten 2 Port USB 2.0 DVI CABLE KVMP Switch (CS-682)

Aten 2 Port USB 2.0 DVI CABLE KVMP Switch (CS-682)
  • 50115_thumb_P_1552528593749
$108.5
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Get a $5 credit or a free drink if order not ready on pick up time.

Delivery:

Next Day Dispatch - Order within 49hrs and 52mins

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Aten 2 Port USB 2.0 DVI CABLE KVMP Switch (CS-682)
  • Model Number:
    CS682-AT
  • Brand:
  • Warranty Period:
    2 Year

Description

Aten 2 Port USB 2.0 DVI CABLE KVMP Switch (CS-682)


  • Superior video quality - up to 1920 x 1200 @ 60 Hz

  • Computer selection via a remote port selector, hotkeys, and USB mouse

  • Independent switching of the KVM and Audio focus - one computer has the KVM focus and the other the Audio focus

  • Built-in all-in-one cables (2 x 1.2 m) and bus-powered design




Specifications


Computer Connections2
Port SelectionHotkey, Mouse, Remote Port Selector
Connectors
Console Ports1 x DVI-D Female (White)
2 x USB Type A Female
1 x 3.5mm Audio Jack Female (Green)
1 x 3.5mm Audio Jack Female (Pink)
KVM Ports2 x DVI-D Male (Black)
2 x USB Type A Male (Purple)
2 x USB Type A Male (Black)
2 x 3.5mm Audio Jack Female (Green)
2 x 3.5mm Audio Jack Female (Pink)
Remote Port Selector1 x 2.5mm Audio Jack Female
LEDs
KVM2 (Green)
Remote Port Selector2 (Green)
Cable Length
KVM2 x 1.2 m
Remote Port Selector1.8 m
Emulation
Keyboard / MouseUSB
Video1920 x 1200 @ 60Hz
Scan Interval3, 5, 10, 20 secs. (default 5 secs.)
Power ConsumptionDC5V:1.95W:22BTU
Environmental
Operating Temperature0 - 50°C
Storage Temperature-20 - 60°C
Humidity0 - 80% RH, Non-condensing
Physical Properties
HousingPlastic
Weight0.49 kg ( 1.08 lb )
Dimensions (L x W x H)11.15 x 7.80 x 2.40 cm
(4.39 x 3.07 x 0.94 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.


Package Contents

  • 1x CS682 2-Port USB 2.0 DVI KVM Switch

  • 1x Remote Port Selector

  • 1x User Instructions
