Output Power Capacity 280 Watts / 450 VA Max Configurable Power 280 Watts / 450 VA Nominal Output Voltage 230V Output Voltage Distortion Less than 5% at full load Output Frequency (sync to mains) 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal Topology Line Interactive Waveform Type Stepped approximation to a sinewave Output Connections (4) IEC 320 C13 (2) IEC Jumpers
Input
Nominal Input Voltage 230V Input Frequency 50/60 Hz +/- 3 Hz (auto sensing) Input Connections IEC-320 C14 Input voltage range for main operations 195 - 265V Input voltage adjustable range for mains operation 151 - 302V
Batteries & Runtime
Battery Type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof Typical recharge time 5 hour(s) Replacement Battery RBC18 RBC Quantity 1
Communications & Management
Interface Port(s) DB-9 RS-232 Control panel LED status display with On Line : On Battery : Replace Battery and Overload indicators Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm Emergency Power Off (EPO) Optional
Surge Protection and Filtering
Surge energy rating 320 Joules Filtering Full time multi-pole noise filtering : 0.7% IEEE surge let-through : zero clamping response time : meets UL 1449 Data Line Protection RJ-11 2-Way Modem/Fax/DSL splitter with protection (four wire dual lines), RJ45 10/100 Base-T Ethernet protection
Physical
Maximum Height 44.00 mm Maximum Width 432.00 mm Maximum Depth 383.00 mm Rack Height 1U Net Weight 10.18 KG Shipping Weight 11.73 KG Shipping Height 164.00 mm Shipping Width 476.00 mm Shipping Depth 589.00 mm Color Grey Units per Pallet 24.00
Environmental
Operating Environment 0 - 40 °C Operating Relative Humidity 0 - 95% Operating Elevation 0-3000 meters Storage Temperature -15 - 45 °C Storage Relative Humidity 0 - 95% Storage Elevation 0-15000 meters Audible noise at 1 meter from surface of unit 38.00 dBA Online Thermal Dissipation 38.00 BTU/hr
Conformance
Regulatory Approvals C-tick, CE, GOST, VDE Standard Warranty 2 years repair or replace
Sustainable Offer Status
RoHS Compliant Other Environmental Compliance China RoHS
