Specifications
DIMENSIONS
420 x 420 x 230 mm (16.54 x 16.54 x 9.06")
WEIGHT
2.22 kg (4.89 lbs)
POWER SUPPLY
24V, 0.5A Gigabit PoE Adapter (Included)
MAX. POWER CONSUMPTION
8.5W
POWER METHOD
Passive PoE (Pairs 4, 5+; 7, 8 Return)
SUPPORTED VOLTAGE RANGE
20 to 26VDC
GAIN
25 dBi
NETWORKING INTERFACE
(1) 10/100/1000 Ethernet Port
PROCESSOR SPECS
MIPS 74Kc
MEMORY
64 MB
LEDS
Power, Ethernet, (4) Signal Strength
CHANNEL SIZES
PtP Mode
PtMP Mode
10/20/30/40/50/60/80 MHz
10/20/30/40 MHz
ENCLOSURE CHARACTERISTICS
Antenna Feed
Dish Reflector
Outdoor UV Stabilized Plastic
Powder-Coated SPCC
MOUNTING
Pole-Mounting Kit (Included)
WIND LOADING
380 N @ 200 km/h (85.4 lbf @ 125 mph)
WIND SURVIVABILITY
200 km/h (125 mph)
ESD/EMP PROTECTION
Air: ± 24 kV, Contact: ± 24 kV
OPERATING TEMPERATURE
-40 to 70° C (-40 to 158° F)
OPERATING HUMIDITY
5 to 95% Noncondensing
ROHS COMPLIANCE
Yes
SALF FOG TEST
IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
VIBRATION TEST
IEC 68-2-6
TEMPERATURE SHOCK TEST
IEC 68-2-14
UV TEST
IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
WIND DRIVEN RAIN TEST
ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
CERTIFICATIONS
CE, FCC, IC
