TP-Link AC1750 Wireless Dual Band Gigabit Ceiling Mount Access Point (EAP245)

Interface

Gigabit Ethernet (RJ-45) Port *2 (Support IEEE802.3af PoE and Passive PoE )

Button

Reset

Power supply

802.3af/A PoE

48V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)

Power consumption

12.3 W

Dimensions ( w x d x h )

8.1 × 7.1 × 1.5 in. (205.5 × 181.5 × 37.1 mm)

Antenna type

Internal Omni

2.4GHz: 3* 3.5dBi

5GHz: 3*4dBi

Mounting

Ceiling /Wall Mounting (Kits included)

Physical security lock

Yes

WIRELESS FEATURES

Wireless standards

IEEE 802.11ac/n/g/b/a

Frequency

2.4GHz and 5GHz

Signal rate

5GHz:Up to 1300Mbps

2.4GHz:Up to 450Mbps

Wireless functions

Multiple SSIDs (Up to 16 SSIDs, 8 for each band)

Enable/Disable Wireless Radio

Automatic Channel Assignment

Transmit Power Control (Adjust Transmit Power on dBm)

QoS(WMM)

MU-MIMO

Seamless Roaming

Band Steering

Load Balance

Airtime Fairness

Beamforming

Rate Limit

Reboot Schedule

Wireless Schedule

Wireless Statistics based on SSID/AP/Client

Wireless security

Captive Portal Authentication

Access Control

Wireless Mac Address Filtering

Wireless Isolation Between Clients

SSID to VLAN Mapping

Rogue AP Detection

802.1X Support

64/128/152-bit WEP / WPA / WPA2-Enterprise,

WPA-PSK / WPA2-PSK

Transmission power

CE：

≤20dBm(2.4GHz)

≤23dBm(5GHz)

FCC:

≤24dBm(2.4GHz)

≤24dBm(5GHz)

MANAGEMENT

OMADA app

Yes

Centralized management

Omada Software Controller

OC200

Cloud access

Yes (Through Omada Software Controller or OC200)

Email alerts

Yes

LED on/off control

Yes

Management MAC access control

Yes

SNMP

Yes

System Logging Local/Remote SYSLOG

Local/Remote Syslog

SSH

Yes

Web-based management

HTTP/HTTPS

L3 management

Yes

Multi-site management

Yes

Management VLAN

Yes

OTHERS

Certification

CE, FCC, RoHS

Package contents

AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP245

Gigabit Passive PoE Adapter

Power Cord

Mounting Kits

Installation Guide

System requirements

Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux

Environment

Operating Temperature: 0℃~40℃ (32℉~104℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
