HARDWARE FEATURES |
|
Plug type | AU |
Standards and protocols | IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Interface | 1 * 10/100/1000M Ethernet Port (RJ45) |
Button | RE (Range Extender) Button, Reset Button, LED Button, Power Button |
Power consumption | 10W（max power consumption） |
Dimensions ( w x d x h ) | 6.4x 3.0 x 2.6 in. (163 x 76.4 x 66.5mm) |
Antenna | 3* external |
WIRELESS FEATURES |
|
Standards and protocols | IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Interface | 1 * 10/100/1000M Ethernet Port (RJ45) |
Frequency | 2.4GHz & 5GHz(11ac) |
Signal rate | 5GHz:Up to 1300Mbps 2.4GHz:Up to 450Mpbs |
Reception sensitivity | 5GHz: 11a 6Mbps:-93dBm@10% PER 11a 54Mbps: -76dBm@10% PER 11ac HT20 mcs8: -68dBm@10% PER 11ac HT40 mcs9: -64dBm@10% PER 11ac HT80 mcs9: -61dBm@10% PER 2.4GHz: 11g 54M: -77dBm@10% PER 11n HT20 mcs7: -73dBm@10% PER 11n HT40 mcs7: -70dBm@10% PER |
Wireless modes | Range Extender/Access Point |
Wireless functions | Wireless Statistic Concurrent Mode Boost Both 2.4G/5G WiFi Band Access Control |
LED control | Domain Login Function Wi-Fi Coverage |
Wireless security | 64/128-bit WEP WPA-PSK / WPA2-PSK |
Transmission power | <20dBm(2.4GHz) <23dBm(5GHz) |
OTHERS |
|
Certification | CE, FCC, RoHS |
Package contents | AC1750 Wi-Fi Range Extender RE450 Quick Installation Guide |
Box dimensions (w x d x h) | 7.9 x 4.9 x 3.4in. (202x 125 x 86mm) |
System requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux. |
Environment | Operating Temperature: 0°C~30°C (32°F~86°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
