Synology Mesh Router (MR2200AC)

Synology Mesh Router (MR2200AC)
  • 47608_thumb_P_1551927350099
  • 47608_thumb_P_1551927369899
  • 47608_thumb_P_1551927369565
  • 47608_thumb_P_1551927370419
$239.0
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Get a $5 credit or a free drink if order not ready on pick up time.

Delivery:

Next Day Dispatch - Order within 0hrs and 0mins

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Synology Mesh Router (MR2200AC)
  • Model Number:
    MR2200AC
  • Brand:
  • Warranty Period:
    2 Year

Description

Please Check Modem/Router Compatibility with your Service Providers Before Purchasing

Synology MR2200AC Mesh Router


Coming with intelligent mesh Wi-Fi capability and best-in-class parental controls, MR2200ac is designed to keep all devices connected and everyone safe. Experience the award-winning Synology Router Manager (SRM) with an MR2200ac, and add more when you are ready to expand your coverage even further.


Synology Mesh Router (MR2200AC)


Specifications


Hardware Specifications
CPUQuad core 717 MHz
Memory256 MB DDR3
Antenna type2x2 MIMO high-performance internal antenna (2.4 GHz / 5 GHz)
LAN portGigabit (RJ-45) x 1
WAN portGigabit (RJ-45) x 1
External PortsUSB 3.0 x 1 (5V, 0.9A power output)
Button and switchWPS, Power, Reset, Wi-Fi On/Off
Appearance
Size (Height x Width x Depth)154 mm x 199 mm x 65 mm
Weight0.45 kg
Temperature
Operating Temperature5°C to 40°C (40°F to 104°F)
Storage Temperature-20°C to 60°C (-5°F to 140°F)
Relative Humidity5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI Class B
  • RCM
  • KC
  • iDA
  • TELEC
  • JATE
  • IC
Wi-Fi Certification
  • CE
  • FCC
  • NCC
  • RCM
  • iDA
  • TELEC
  • KC
  • IC
Warranty2 Years
Others
AC Input Power Voltage100V to 240V AC
Power Frequency50/60 Hz, Single Phase
Power Consumption*12.95 W (Access)
5.21 W (Idle)
Wireless
IEEE 802.11ac
  • IEEE 802.11a/b/g/n/ac
  • Simultaneous tri-band Wi-Fi
  • 5GHz-1: 867Mbps
  • 5GHz-2: 867Mbps
  • 2.4GHz: 400Mbps
IEEE 802.11ac wave 2MU-MIMO
Wi-Fi EncryptionWEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, Wi-Fi Enhanced Open (OWE)
Wi-Fi MAC address filter
Maximum MAC filters64
Seamless roaming802.11k/v/r standard support
Beamforming
DFS
Schedulable Wi-Fi
Guest Network
Guest Portal
Customized page style
Connection time limit
Password Rotation
WPS 2.0 (Wi-Fi Protected Setup 2.0)
3G/4G Dongle & Tethering (Learn more)
Maximum connected devices90
Wi-Fi Point
Primary Wi-Fi Point
Network
Internet connectionDynamic IP, Static IP, PPPoE, PPTP, DS-Lite (AFTR)
3G/4G LTE dongle
Android tethering
iPhone tethering
NoteiPhone tethering only supported your Synology Router running SRM 1.2 or above
Operating mode
  • Wireless Router
  • Wireless AP
Port forwardingSetup via manual management or UPnP
Maximum port forwarding rules64
Maximum UPnP rules64
Port triggering
Maximum port triggering rules32
Minimum port triggering timeout30s
Maximum port triggering timeout3600s
DMZ
IPv6IPv6 DHCP server / client, DS-Lite, 6in4, 6to4, 6rd, Dual-Stack, DHCPv6-PD, IPv6 Relay, FLET's IPv6
DHCPServer/client mode, client list, MAC address reservation
Maximum DHCP reservations500
LAN/WLAN IGMP snooping
VPN
  • VPN server (WebVPN, SSL VPN, SSTP, OpenVPN, L2TP/IPSec, PPTP, Site-to-Site)
  • VPN client (PPTP, OpenVPN, L2TP/IPSec)
  • VPN Pass-through (PPTP, IPSec, L2TP)
Policy route, Static route, Network Address Translation (NAT), PPPoE relay
Maximum IPv4 static routes100
Maximum IPv6 static routes100
Diagnosis tools
  • Ping
  • Traceroute
Safe Access
Parental Control
User Profile15
Network Profile2
Customized Internet schedule
Time Quota
IPv4/IPv6 DNS-based web filter
  • Schedule
  • Database
  • Request to unblock
Customized allow/block list
  • Maximum blocked URLs: 100
  • Maximum allowed URLs: 100
Pause Internet
Reward
Log
Report
Security
Safe SearchBing, Google, YouTube
Threat Intelligence Databasesupport in IPv4 & IPv6
Google Safe Browsingsupport in IPv4 & IPv6
Database auto updateThreat Intelligence Database, Google Safe Browsing, DNS-based web filter
Traffic Control
Internet ban, device speed & priority
Application layer (L7) quality of service (QoS)
Maximum device rules64
Maximum application rules per device32
Traffic Monitor
Live view
Historical statisticsDaily, Weekly, Monthly, Annual
Website history
Application Detection
Traffic Report
Country auto update
Schedulable
Traffic analysis periodDaily, Weekly, Monthly, Annual
Export formats.CSV, .HTML
VPN Plus Server
VPN Plus ServerEasily create and manage secure VPN access through a web browser or client. Supports various VPN services — Site-to-Site VPN, WebVPN, SSL VPN, Remote Desktop, SSTP, OpenVPN, L2TP over IPSec, and PPTP
Maximum Client VPN Access License10
Site-to-Site VPN
Maximum Site-to-Site VPN Tunnels4
Remote Desktop (RDP + VNC)3
Connection List
Log
Report
Package Center
Cloud Station ServerSync data from multiple platforms, centralizing it on the router while easily keeping historical versions of important files
Maximum Concurrent File Transfers64
NoteCloud Station ShareSync is not supported
DNS ServerHelps users find and translate domain names into IP addresses
Download StationSupported download protocols: BT/HTTP/FTP/NZB/eMule
Maximum concurrent download tasks50
Maximum concurrent BT download tasks20
Media Server (DLNA/UPnP®)
  • Media indexing
  • DLNA Compliance
  • PS3/PS4/Xbox 360/Xbox One supported
RADIUS ServerProvides centralized authentication, authorization, and accounting for wireless network access
Mobile Apps
DS router (Android/iOS)
  • First Time Installation
  • Network overview
  • Wi-Fi management
  • Wi-Fi system topology
  • Safe Access
  • Traffic Control
  • Network security (firewall, port forwarding, Internet ban)
  • Wake on LAN
  • System Update
VPN Plus (Android/iOS)
DS cloud (Android/iOS)
DS get (Android)
DS file (Android/iOS)
Management
Operating systemSynology Router Manager (SRM)
Free OS upgrade
Anywhere access to SRMSynology QuickConnect & Dynamic DNS (DDNS)
SecurityFirewall/SPI Firewall, DoS Protection, VPN Pass-through (PPTP, IPSec, L2TP), Auto block, SSL certificate, Security Advisor, two-factor authentication
Wake on LAN (WOL)
WOL over QuickConnect
Maximum connected devices100
NotificationEmail, SMS, push service (via DS router)
SSH
SNMP
Configuration backup & restore
User account management
Printer serverMaximum printer: 1
USB/SD Card File Service
File SystemEXT4, FAT, NTFS, HFS+
Access support
  • File explorer (via LAN only)
  • Web browsers: Chrome™, Firefox®, Internet Explorer®: 11 onwards, Safari® 11 onwards
  • Mobile device: DS file
Protocol supportWindows file service (CIFS), Mac file service (AFP), FTP/FTPS, WebDAV
Apple Time Machine
Shared Folder privileges
Storage hibernation
Environment & Packaging
EnvironmentRoHS Compliant
Packaging Content
  • Main Unit X 1
  • AC Power Adapter X 1
  • RJ-45 LAN Cable X 1
  • Quick Installation Guide X 1
