Recommended CPU speed (GHz): 1.4 (1 camera) Recommended PC memory (MB): 384 (1 camera) PC Video card memory (MB): 32 (1-2 cameras) Recommended DirectX 9 compatible Display resolution: 1024 x 768 pixels or higher, 32-bit color Hard drive (MB): 100 MB for program and a minimum of 500+ MB for video storage Operating system: Microsoft Windows Vista (32/bit) Microsoft Windows XP Home Edition, XP Professional or XP Media Center Edition Internet access required Logitech Master System required
Basic
Processing Power: 400 MHz DSP Image Encoding: Windows Media Video 9 Image Processing: Motion detection up to 16 zones, Auto brightness Resolution: Selectable: 640 x 480 pixels or 320 x 240 pixels Frame Rate: Selectable: 15, 10, or 5 frames/second Bit Rate: Selectable Color Depth: 10 bits Illumination: 2 lx minimum per IEC 61146-1
Operating Temp. Range: +32F to +93 F (0 C to +34 C) Storage Temp Range: -4 F to +140 F (-20 C to +60 C) Humidity (storage and operating): 5% to 95% (relative; non-condensing) Voltage: 110 Volts AC, 60 Hz Power supply to Camera cabling: CAT-5e, RJ-45 connectors, 10 feet (3 m) User Provided requirements: CAT-5e, RJ-45 connectors, up to 120 feet (36 m) Connector pin out: Per IEEE 802.3 Property Size: Up to 10,000 square feet
Physical Dimensions
Power Consumption: 15 Watts Camera Body Dimensions: Height: 5.0 inches (12.7 cm) Width 3.2 inches (8.1 cm) Depth: 1.8 inches (4.6 cm) Power Supply Dimensions: Height: 3.8 inches (9.7 cm) Width 2. 9 inches (7.4 cm) Depth: 2.6 inches (6.6 cm) Camera Weight: 6.1 oz (173 g)
Package Contents
Logitech Indoor Security Camera Logitech power supply Window mount Desktop stand Wall mount Window decals Camera ethernet cable (10-foot)
* Specifications are subject to change without notice. * Specifications may vary. * The product picture(s) is only for your reference, it may differ from the actual product.
