CPU SPECIFICATIONS |
|
Total Cores | 20 |
# of Performance-cores | 8 |
# of Efficient-cores | 12 |
Total Threads | 20 |
Max Turbo Frequency | 5.5 GHz |
IntelĀ® Turbo Boost Max Technology 3.0 Frequency | 5.5 GHz |
Performance-core Max Turbo Frequency | 5.4 GHz |
Efficient-core Max Turbo Frequency | 4.6 GHz |
Performance-core Base Frequency | 3.9 GHz |
Efficient-core Base Frequency | 3.3 GHz |
Cache | 30 MB IntelĀ® Smart Cache |
Total L2 Cache | 36 MB |
Processor Base Power | 125 W |
Maximum Turbo Power | 250 W |
IntelĀ® Deep Learning Boost (IntelĀ® DL Boost) on CPU | Yes |
AI Software Frameworks Supported by CPU | OpenVINOā¢, WindowsML, DirectML, ONNX RT, WebNN |
CPU Lithography | TSMC N3B |
SUPPLEMENTAL INFORMATION |
|
Embedded Options Available | No |
Use Conditions | PC/Client/Tablet |
MEMORY SPECIFICATIONS |
|
Max Memory Size (dependent on memory type) | 192 GB |
Memory Types | Up to DDR5 6400 MT/s |
Maximum Memory Speed | 6400 MHz |
Max # of Memory Channels | 2 |
NPU SPECIFICATIONS |
|
NPU Name | IntelĀ® AI Boost |
NPU Peak TOPS (Int8) | 13 |
Sparsity Support | Yes |
Windows Studio Effects Support | Yes |
AI Software Frameworks Supported by NPU | OpenVINOā¢, WindowsML, DirectML, ONNX RT, WebNN |
EXPANSION OPTIONS |
|
Direct Media Interface (DMI) Revision | 4 |
Max # of DMI Lanes | 8 |
IntelĀ® Thunderboltā¢ 4 | Yes |
Scalability | 1S Only |
PCI Express Revision | 5.0 and 4.0 |
PCI Express Configurations | Up to 1x16+2x4, 2x8+2x4, 1x8+4x4 |
Max # of PCI Express Lanes | 24 |
PACKAGE SPECIFICATIONS |
|
Sockets Supported | FCLGA1851 |
Thermal Solution Specification | PCG 2020A |
Max Operating Temperature | 105 Ā°C |
ADVANCED TECHNOLOGIES |
|
IntelĀ® Volume Management Device (VMD) | Yes |
IntelĀ® Gaussian & Neural Accelerator | 3.5 |
IntelĀ® Thread Director | Yes |
IntelĀ® Speed Shift Technology | Yes |
IntelĀ® Turbo Boost Max Technology 3.0 | Yes |
IntelĀ® Turbo Boost Technology | 2.0 |
IntelĀ® 64 | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | IntelĀ® SSE4.1, IntelĀ® SSE4.2, IntelĀ® AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStepĀ® Technology | Yes |
Thermal Monitoring Technologies | Yes |
SECURITY & RELIABILITY |
|
IntelĀ® Standard Manageability (ISM) | Yes |
IntelĀ® Control-Flow Enforcement Technology | Yes |
IntelĀ® AES New Instructions | Yes |
Secure Key | Yes |
IntelĀ® Trusted Execution Technology | Yes |
Execute Disable Bit | Yes |
IntelĀ® OS Guard | Yes |
IntelĀ® Boot Guard | Yes |
Mode-based Execute Control (MBEC) | Yes |
IntelĀ® Virtualization Technology (VT-x) | Yes |
IntelĀ® Virtualization Technology for Directed I/O (VT-d) | Yes |
IntelĀ® VT-x with Extended Page Tables (EPT) | Yes |
