USB 3.2 Gen1 Type-B Male (Blue) (USB-B to USB-C and USB-B to USB-A cable package included)
Video Output
1 x HDMI Type A Female (PGM Video, Black)
Audio Inputs
1x balanced analog audio via XLR connectors 1x unbalanced audio via RCA connectors.
Video Resolution
Video input: 2160p30/25/24, 1080p60/50/30/25/24, 720p60/50, HDMI 1.4b support
PGM video out: 1080p60/50/30/25/24, 720p60/50, HDMI 1.4b support (unencrypted) (Support encrypted PGM output at 2160p30/25/24, 1080p60/50/30/25/24, 720p60/50 with UVC capture disabled)
Audio Sampling
16-bit PCM audio, 44.1KHz and 48KHz
Output
Uncompressed 1080p60 & 720p60 UVC video stream with UAC audio (Uncompressed video stream is only available on USB3.1 connection)
ENVIRONMENTAL
Operating Temperature
0 - 40 ºC
Storage Temperature
-20 – 60 ºC
Humidity
0 - 80% RH, Non-Condensing
Minimum Hardware Requirements
PC/Mac: CPU: Intel® i3 Dual Core 2.8Ghz or higher RAM: 4GB or more One USB-C interface or USB-A interface
Smartphone: Android device with UVC support and USB-C interface*
*For detail UVC compatible device list, please refer to following info revealed by third party App. https://www.camerafi.com/supported-devices/
Connection
Bluetooth Low Energy(BLE) technology
OS Support
Windows 10 and above * Mac OS X 10.13 and above Android 5.x and above or iOS 10.1 and above , with Bluetooth 4.2 or higher supporting Bluetooth Low Energy (BLE)
*Window 7 requires driver installation
Physical Properties
Housing
Metal
Weight
0.68 kg ( 1.5 lb )
Dimensions (L x W x H)
13.00 x 15.18 x 4.25 cm (5.12 x 5.98 x 1.67 in.)
Note
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
